Continuous output 50W+50W (8Ω, when both ch operation)
60W/60W (8Ω, when operating in one channel)
Total harmonic distortion 0.04% or less (8Ω, 50W)
Mixed modulation distortion rate 0.04% or less (8Ω, 50W, 70:7kHz=4:1)
Output bandwidth 5Hz to 50kHz -3dB (0.04%)
Frequency characteristics 10Hz to 60kHz (within-1dB)
Input sensitivity 580mV (8Ω, 50W)
Input impedance 50kΩ
Damping factor 40(8Ω)
80(16Ω)
Residual noise 1mV or less

Frequency characteristics 10Hz to 50kHz -3dB (Aux1)
Total harmonic distortion 0.05% or less (1kHz, 1V, Aux1)
Input sensitivity Phono1,2:2mV
Aux1:90mV or more (adjustable)
Aux2,3:80mV
Input impedance Phono1:30kΩ, 50kΩ, 100kΩ
Phono2:50kΩ
Aux1:50kΩ
Aux2,3:200kΩ
SN ratio Phono1,2:63dB or more
Aux1, 2 and 3:80dB or more
Maximum allowable input (1kHz) Phono:300mV
Tone control LUX method NF type with curved point switching
Low range curvature point:feat, 150Hz, 300Hz, 600Hz
High range curvature point:feat, 6kHz, 3kHz, 1.5kHz
Residual noise 25μV or less
Crosstalk (1kHz) Phono: -60dB or less
Aux:-65dB or less
Filter Low cut: 70Hz (-6dB/oct)
High cut: 6kHz (-6dB/oct)
Roast booster 100Hz(6dB/oct)

Auxiliary device Attenator (-18dB)
Speaker switch (2 systems)
Pre-main separation switch
Tape monitor (2 systems)
Recording output terminal (2 systems)
Semiconductors used Transistors: 33
Diodes: 2
Barista: 4
Power consumption 200W (8Ω simultaneous load at maximum output)
External dimensions 450mm wide x 160mm high x 268mm deep
Weight 11kg
